Description
Specification
|
NO
|
PERFORMANCE
|
UNIT
|
SPECIFICATION
|
|
QD20
|
QD25
|
QD30
|
|
1
|
RATED DRAWBAR PULL
|
N
|
3900
|
4200
|
4500
|
|
2
|
MAX. DRAWBAR PULL
|
N
|
21000
|
22000
|
23000
|
|
3
|
MAX. TOWED WEIGHT
|
Kg
|
20000
|
25000
|
30000
|
|
4
|
MAX. TRAVELING SPEED
（NO/FULL LOAD）
|
km/h
|
28/15
|
28/13
|
28/11
|
|
5
|
OVERALL LENGTH
|
mm
|
2980
|
2995
|
3020
|
|
6
|
OVERLL WIDTH
|
mm
|
1440
|
|
7
|
OVERALL HEIGHT
|
mm
|
1380
|
1400
|
|
8
|
WHEELBASE
|
mm
|
1900
|
|
9
|
TREAD(FONRT/REAR)
|
mm
|
1220/1160
|
1220/1160
|
1220/1160
|
|
10
|
FRONT OVERHANG
|
mm
|
460
|
460
|
460
|
|
11
|
REAR OVERHANG
|
mm
|
495
|
495
|
495
|
|
12
|
WEIGHT
|
SERVICE WEIGHT
|
kg
|
3500
|
3600
|
3720
|
|
FRONT AXLE WEIGHT
|
1360
|
1380
|
1430
|
|
REAR AXLE WEIGHT
|
2140
|
2220
|
2290
|
|
13
|
CERNTER COUPLER HEIGHT
(ADJUSTABLE HEIGHT
|
mm
|
305/405
|
305/405
|
305/405
|
|
14
|
GRADEABILITY NO LOAD
|
%
|
30
|
30
|
30
|
|
15
|
MIN TURNING RADIUS
|
mm
|
3100
|
3100
|
3050
|
|
16
|
MIN. GROUND CLEARANCE
|
mm
|
150
|
150
|
150
|
|
17
|
APPROCHING ANGLE
|
°
|
35°
|
35°
|
35°
|
|
18
|
DEPARTURE ANGLE
|
°
|
27°
|
27°
|
27°
|
|
19
|
BATTERY(VOLTAGE/CAPACITY)
|
V/Ah
|
80V/690Ah
|
80V/690Ah
|
80V/690Ah
|
|
20
|
BATTERY INSULATION RESISTANCE (MEASURED)
|
MΩ
|
63.7
|
63.7
|
63.7
|
|
21
|
Insulation resistance (measured) of body with the motor terminal
|
MΩ
|
10
|
10
|
10
|
|
22
|
FRONT WHEEL
|
|
6.00-9-10PR
|
|
23
|
REAR WHEEL
|
|
7.00-12-12PR
|
|
24
|
SEAT FOR DRIVER and passenger
|
QTY.
|
2
|
2
|
2
|
|
25
|
CONTINOUS WORKING HOUR FULL LOAD
|
h
|
3
|
3
|
3
|
|
26
|
DRIVING MILEAGE
NO/FULL LOAD
|
km
|
180/50
|
180/50
|
180/50
|
|
27
|
FULLY CHARGING HOUR
|
h
|
≤8
|
≤8
|
≤8
|
|
28
|
CONTROLLER FOR SPEED
|
TYPE
|
|
AC SPEED REGULATION
|
|
RATED VOLTAGE
|
V
|
80
|
80
|
80
|
|
OVER CURRENT PROTECTION
|
A
|
450
|
450
|
450
|
|
29
|
MOTOR for traveling
|
TYPE
|
|
3-PHASE AC
|
|
Rated power
|
KW/rpm
|
28.7/2420
|
28.7/2420
|
28.7/2420
|
|
Rated current(S2)
|
A
|
400
|
400
|
400
|
|
Rated voltage
|
V
|
50
|
50
|
50
|
|
Inslation level
|
|
H
|
H
|
H
|
|
IP level
|
|
43
|
43
|
43
|
|
30
|
STEERING SYTEM
|
|
EPS
|
