Description
Specification
|
Characteristics
|
|
1.1
|
Manufacturer
|
|
JJCC
|
JJCC
|
JJCC
|
JJCC
|
|
1.2
|
Model designation
|
|
CPD20F8
|
CPD25F8
|
CPD30FT(H)
|
CPD35FT
|
|
1.3
|
Drive unit
|
|
Electrics
|
Electrics
|
Electrics
|
Electrics
|
|
1.4
|
Operator type
|
|
Rider seated
|
Rider seated
|
Rider seated
|
Rider seated
|
|
1.5
|
Load capacity
|
Q (kg)
|
2000
|
2500
|
3000
|
3500
|
|
1.6
|
Load center
|
c (mm)
|
500
|
500
|
500
|
500
|
|
Weights
|
|
2.1
|
Service weight
|
kg
|
3860
|
4030
|
4985
|
5100//5300
|
|
Wheels, Chassis
|
|
3.1
|
Tyre type
|
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
Pneumatic
|
|
Dimensions
|
|
4.1
|
Mast/ fork carriage tilt, forward/ backward
|
α/ β (°)
|
6/ 11
|
6/ 11
|
6/ 12
|
6/ 12
|
|
4.2
|
Height, mast lowered
|
h1 (mm)
|
2180
|
2180
|
2025
|
2025
|
|
4.3
|
Free lift
|
h2 (mm)
|
120
|
120
|
100
|
100
|
|
4.4
|
Lift height
|
h3 (mm)
|
3000
|
3000
|
3000
|
3000
|
|
4.5
|
Height, mast extended
|
h4 (mm)
|
4010
|
4010
|
4250
|
4250
|
|
4.19
|
Overall length
|
l1 (mm)
|
3376
|
3376
|
3620
|
3670
|
|
4.2
|
Length to face of forks
|
l2 (mm)
|
2346
|
2346
|
2550
|
2600
|
|
4.21
|
Overall width
|
b1/ b2 (mm)
|
1252
|
1252
|
1220
|
1220
|
|
4.22
|
Fork dimensions
|
s/ e/ l (mm)
|
40×120×1070
|
40×120×1070
|
45×125×1070
|
50×125×1070
|
|
4.33
|
Aisle width, 1000×1200 pallet crossways
|
Ast (mm)
|
4235
|
4235
|
4125
|
4225
|
|
4.34
|
Aisle width, 800×1200 pallet lengthways
|
Ast (mm)
|
4285
|
4285
|
3925
|
4025
|
|
4.35
|
Outer turning radius
|
Wa (mm)
|
2135
|
2135
|
2300
|
2300
|
|
Performance
|
|
5.1
|
Travel speed, laden/ unladen
|
km/ h
|
13/ 13.5
|
13/ 13.5
|
11/ 12
|
11/12
|
|
5.2
|
Lifting speed, laden/ unladen
|
m/ s
|
0.3/ 0.45
|
0.3/ 0.45
|
0.23/ 0.37
|
0.23/ 0.37
|
|
5.3
|
Lowering speed, laden/ unladen
|
m/ s
|
0.44/ 0.435
|
0.44/ 0.435
|
0.50/ 0.48
|
0.50/ 0.48
|
|
5.6
|
Maximum drawbar pull, laden S2 5 min.
|
N
|
17000
|
17000
|
18000
|
18000
|
|
5.8
|
Maximum gradeability, laden/ unladen S2 5 min.
|
%
|
10.5/14
|
10.5/14
|
10.5/12
|
10.5/12
|
|
Drive
|
|
6.1
|
Drive motor rating S2 60 min.
|
kW
|
11
|
11
|
11.75
|
11.75
|
|
6.2
|
Lift motor rating at S3 15%
|
kW
|
8.6
|
8.6
|
10
|
10
|
|
6.4
|
Battery voltage/ rated capacity (5h)
|
V/ Ah
|
48/600(Max770)
|
48/630(Max770)
|
80/500(Max550)
|
80/500(Max550)
|
|
Others
|
|
8.1
|
Type of drive control
|
|
AC ZAPI
|
AC ZAPI
|
AC ZAPI
|
AC ZAPI
|
